AQDWR: Lights

Primary Carry
	JETBeam Raptor RRT-0 XML (T6) Output (regulated) and Duration: Max (IMR16340): 550 ANSI lumens for 15 min Max (CR123A): 260 ANSI lumens for 1.25 hr Max (AA): 110 ANSI lumens for 3.75 hr Min (CR123A): 0.005 ANSI lumens for 100 hr Primary Modes: continuous adjustment Secondary Modes: strobe Ring: twist for high to low and strobe Button: push for off/on, half-push for momentary on Emitter: white Cree XM-L T6 LED Lens: ultra-clear mineral glass with anti-reflective coating Body: aero-grade aluminum alloy Finish: black Type III hard anodized Lens, Control, and Tail Rings: stainless steel Waterproofing: IPX-8 to 2m (6.6') Impact Resistance: US MIL-STD-810F Length: CR123A or IMR16340: 100mm (3.9") With AA extension: 116mm (4.6") Diameter: Head: 25.4mm (1.0") Body: 20.5mm (0.8") Weight (w/o battery): CR123A or IMR16340: 72g (2.5oz) With AA Extension: 83g (2.9oz) Batteries: one CR123A, IMR16340, or AA (with extension) Excellent throw (150m / 500') for a light this size.
	4Sevens Quark MiNiX 123 (T6) Output (regulated): 210 / 45 / 1.2 OTF lumens Duration: 1 / 6.5 / 100 hr Primary Modes: low, medium, high Secondary Modes: strobe, SOS, low beacon, high beacon Bezel: twist for off/on, fast twist for low/medium/high Emitter: white Cree XM-L T6 LED Lens: optical-grade glass with anti-reflective coatings Reflector: "orange-peel" textured Body: T-6061 aluminum Finish: black Type III hard anodized Waterproofing: IPX-8 Length: 58mm (2.3") Diameter: 20mm (0.80") Weight: 18g (0.62oz) w/o battery Batteries: one CR123A
	Photon Freedom Duration: 12 hr (longer on lower settings) Button: push for mode selection (brightness/flashing) Emitter: white Nichia LED Body: fiberglass reinforced polyurethane Finish: black Size: 38×23×10mm (1.5"×0.9"×0.4") Weight: 6g (0.2oz) Batteries: two CR2016 lithium

Primary Carry

JETBeam Raptor RRT-0 XML (with AA extension)

JETBeam Raptor RRT-0 XML (T6)

Output (regulated) and Duration:
- Max (IMR16340): 550 ANSI lumens for 15 min
- Max (CR123A): 260 ANSI lumens for 1.25 hr
- Max (AA): 110 ANSI lumens for 3.75 hr
- Min (CR123A): 0.005 ANSI lumens for 100 hr
Primary Modes: continuous adjustment
Secondary Modes: strobe
Ring: twist for high to low and strobe
Button: push for off/on, half-push for momentary on
Emitter: white Cree XM-L T6 LED
Lens: ultra-clear mineral glass with anti-reflective coating
Body: aero-grade aluminum alloy
Finish: black Type III hard anodized
Lens, Control, and Tail Rings: stainless steel
Waterproofing: IPX-8 to 2m (6.6')
Impact Resistance: US MIL-STD-810F
Length:
- CR123A or IMR16340: 100mm (3.9")
- With AA extension: 116mm (4.6")
Diameter:
- Head: 25.4mm (1.0")
- Body: 20.5mm (0.8")
Weight (w/o battery):
- CR123A or IMR16340: 72g (2.5oz)
- With AA Extension: 83g (2.9oz)
Batteries: one CR123A, IMR16340, or AA (with extension)

Excellent throw (150m / 500') for a light this size.

4Sevens Quark MiNiX 123 (T6)

Output (regulated): 210 / 45 / 1.2 OTF lumens
Duration: 1 / 6.5 / 100 hr
Primary Modes: low, medium, high
Secondary Modes: strobe, SOS, low beacon, high beacon
Bezel: twist for off/on, fast twist for low/medium/high
Emitter: white Cree XM-L T6 LED
Lens: optical-grade glass with anti-reflective coatings
Reflector: "orange-peel" textured
Body: T-6061 aluminum
Finish: black Type III hard anodized
Waterproofing: IPX-8
Length: 58mm (2.3")
Diameter: 20mm (0.80")
Weight: 18g (0.62oz) w/o battery
Batteries: one CR123A

Photon Freedom

Duration: 12 hr (longer on lower settings)
Button: push for mode selection (brightness/flashing)
Emitter: white Nichia LED
Body: fiberglass reinforced polyurethane
Finish: black
Size: 38×23×10mm (1.5"×0.9"×0.4")
Weight: 6g (0.2oz)
Batteries: two CR2016 lithium

Secondary Carry
	4Sevens Quark AA / 123 (R5) Output (regulated): 14500 or R16340: 229 / 85 / 22 / 4 / 0.2 OTF lumens CR123A: 205 / 85 / 22 / 4 / 0.2 OTF lumens AA: 109 / 85 / 22 / 4 / 0.2 OTF lumens Duration: CR123A: 0.8 / 2.7 / 13 / 60 / 360 hr AA: 1.2 / 1.5 / 6 / 48 / 240 hr Modes: moonlight, low, medium, high, max, SOS, beacon, strobe Bezel: twist for general/max mode Button: push for off/on, soft-push for level Emitter: white Cree XP-E R5 LED Lens: impact-resistant glass with sapphire coating Body: T-6061 aluminum Finish: black Type III hard anodized Waterproofing: IPX-8 Length: AA body: 97mm (3.8") CR123A body: 81mm (3.2") Diameter: 22mm (0.86") Weight: AA body: 51g (1.8oz) w/battery CR123A body: 40g (1.4oz) w/battery Voltage Range: 0.9-4.2V Batteries: one AA, R14500, CR123A, or R16340 Optional Clip: deep-pocket carry
	4Sevens Quark Prism Attaches to any full-sized Quark to bend the light path Angle: 90° Body: Rubber Size: 34×28×25mm (1.3×1.1×1.0")
	Streamlight Nano Output: 10 emitter lumens Duration: 8 hr Bezel: twist for off/on Emitter: white 5mm LED Body: aluminum Finish: black hard anodized Length: 37mm (1.47") Diameter (head): 13mm (0.51") Diameter (body): 11mm (0.43") Weight: 10g (0.36oz) w/battery Batteries: four LR41 alkaline

General
	Surefire Z2 CombatLight (modified) Output: 270 emitter lumens (regulated) Duration: 1.5 hr Bezel: twist for off/on Button: push for momentary on Emitter: white Cree XR-E Q5 LED Body: aluminum Finish: black anodized Length: 130mm (5.1") Diameter: 32mm (1.25") Weight: 136g (4.8oz) w/batteries Batteries: two CR123A
	Fenix P3D (Q5) Output: 215 / 120 / 53 / 12 emitter lumens (regulated) Duration: 1.8 / 4.8 / 13 / 65 hr Bezel: twist for general/turbo mode Button: push for off/on, soft-push for level Emitter: white Cree XR-E Q5 LED Body: aluminum Finish: natural hard anodized Length: 114mm (4.5") Diameter: 21mm (0.83") Weight: 48g (1.7oz) w/o battery Batteries: two CR123A
	Pila GL3 (modified) LEDs Upgraded by Scott Clawson (email to scott(at)release1(dot)com) Output: 200 / 15 emitter lumens Duration: 20 min / 50 hr Bezel: twist for off/low/high Button: push for momentary high Emitter: Pila 9V xenon bulb and 4 white 5mm Nichia LEDs Body: aluminum Finish: black anodized Length: 165mm (6.5") Diameter: 36mm (1.4") Weight: 190g (6.7oz) w/o batteries Batteries: three CR123A
	Fenix L2D (Q5) Output: 180 / 107 / 53 / 12 emitter lumens (regulated) Duration: 2.4 / 4 / 10.5 / 55 hr Bezel: twist for general/turbo mode Button: push for off/on, soft-push for level Emitter: white Cree XR-E Q5 LED Body: aluminum Finish: olive green hard anodized Length: 147mm (5.8") Diameter: 21mm (0.83") Weight: 57g (2.0oz) w/o battery Batteries: two AA
	Fenix P2D (Q5) Output: 180 / 107 / 53 / 12 emitter lumens (regulated) Duration: 1 / 2 / 5.5 / 30 hr Bezel: twist for general/turbo mode Button: push for off/on, soft-push for level Emitter: white Cree XR-E Q5 LED Body: aluminum Finish: olive green hard anodized Length: 78mm (3.1") Diameter: 21mm (0.83") Weight: 37g (1.3oz) w/o battery Batteries: one CR123A
	Fenix P1D (Q5) Output: 180 / 96 / 16 emitter lumens (regulated) Duration: 1 / 2.8 / 21 hr Bezel: twist for off/on, fast twist for medium/low/high/Strobe/SOS Emitter: white Cree XR-E Q5 LED Body: aluminum Finish: olive green hard anodized Length: 71mm (2.8") Diameter: 21mm (0.83") Weight: 28g (1.0oz) w/o battery Batteries: one CR123A
	NiteCore EZ AA (Q5) Output: 130 / 15 OTF lumens (regulated) Duration: 1.5 / 20 hr Bezel: twist for off/low/high Emitter: white Cree XR-E LED Body: aluminum Finish: black Type III hard anodized Length: 83mm (3.3") Diameter: 16.6mm (0.65") Weight: 20g (0.7oz) w/o battery Batteries: one AA (max 2V)
	Surefire G2 Nitrolon Output: 120 OTF lumens Duration: 20 min Button: push for momentary Bezel: twist for off/on Emitter: Surefire P61 xenon bulb Body: Nitrolon polymer Finish: black Length: 124mm (4.9") Diameter: 32mm (1.25") Weight: 116g (4.1oz) w/batteries Batteries: two CR123A
	Maratac AAA (Q5) Made by iTP based on the A3 EOS Upgrade Edition Output: 80 / 18 / 1.5 OTF lumens (regulated) Duration: 0.8 / 4 / 50 hr Bezel: twist for off/on, fast twist for medium/low/high Emitter: white Cree XR-E Q5 LED Body: aluminum Finish: natural Type III hard anodized Length: 66.5mm (2.6") Diameter: 14mm (0.5") Weight: 9g (0.3oz) w/o battery Batteries: one AAA
	Fenix LD01 (Q5) Output: 80 / 27 / 10 emitter lumens (regulated) Duration: 1 / 3.5 / 8.5 hr Bezel: twist for off/on, fast twist for medium/low/high Emitter: white Cree XR-E Q5 LED Body: aluminum Finish: black Type III hard anodized Length: 74mm (2.9") Diameter: 15mm (0.6") Weight: 14g (0.5oz) w/o battery Batteries: one AAA
	Arc Flashlight Arc-AAA Premium Output: 5.5 OTF lumens (regulated) Duration: 9 hr Bezel: twist for off/on Emitter: white 5mm Nichia CS LED Body: aluminum Finish: natural Type III hard anodized Length: 69mm (2.7") Diameter: 13mm (0.5") Weight: 21g (0.75oz) w/battery Batteries: one AAA
	Essential Gear PICO Lite Output: 10 emitter lumens Duration: 15 hr Bezel: twist for off/on Emitter: white 5mm LED Body: 6061 aluminum Finish: anodized Color: titanium Waterproof: IPX4 Length: 38mm (1.5") Diameter: 13mm (0.5") Weight: 6g (0.2oz) w/o battery Batteries: four LR41 alkaline
	Princeton Tec Aurora Duration: 50 / 110 / 160 hr Button: push for mode selection (low/medium/high/fast/slow) Emitter: 3 white 5mm LEDs Body: plastic Finish: blue Headband: 25mm (1") elastic single-loop Size: 57×44×25mm (2.25"×1.75"×1") Weight: 79g (2.8oz) w/batteries Batteries: three AAA

Name	Voltage	Capacity	Chemistry	Rechargable	Length	Diameter	Notes
AA	1.5V	2700maH	alkaline	no	50.5mm	14.5mm
R14500	3.6V		lithium ion	yes	50mm	14mm	Either ICR14500 or IMR14500. Similar in size to AA.
ICR14500	3.6V	750maH	lithium ion cobalt	yes	50mm	14mm	Similar in size to AA.
IMR14500	3.6V	600maH	lithium ion manganese	yes	50mm	14mm	Similar in size to AA.
AAA	1.5V	1200maH	alkaline	no	44.5mm	10.5mm
CR123A	3.0V	1500maH	lithium	no	34.5mm	17mm
R16340	3.6V		lithium ion	yes	34mm	16mm	Either ICR16340 or IMR16340. Similar in size to CR123A.
ICR16340	3.6V	750maH	lithium ion cobalt	yes	34mm	16mm	Similar in size to CR123A.
IMR16340	3.6V	550maH	lithium ion manganese	yes	34mm	16mm	Supports high discharge rates. Similar in size to CR123A.
CR2032	3.0V	225maH	lithium	no	3.2mm	20mm
CR2016	3.0V	90maH	lithium	no	1.6mm	20mm
LR41	1.5V	45maH	alkaline	no	3.6mm	7.9mm
